Рулевая рейка и наконечники TOYOTA SPRINTER, 1991/06 - 1995/05, 1,3 литра, 16 клапанов, DOHC, EFI, 4 двери, LX SPECIFICATION, EE101, автомат, АКПП, 3 ступени

Каталог

Япония

Модель

SPRINTER

Двигатель

1,3 литра, 16 клапанов, DOHC, EFI

Кузов

4 двери

Класс

LX SPECIFICATION

Фрейм

EE101

Трансмиссия

автомат АКПП, 3 ступени

Опции

Код

Описание

04445A

GASKET KIT, POWER STEERING GEAR(FOR RACK & PINION)

04455

GASKET KIT, POWER STEERING CONTROL VALVE OVERHOLE

44250

GEAR ASSY, POWER STEERING(FOR RACK & PINION)

45046

END SUB-ASSY, TIE ROD, RH

45046A

NUT, CASTLE(FOR TIE ROD END)

45047

END SUB-ASSY, TIE ROD, LH

45514

BRACKET, STEERING RACK HOUSING, NO.1

45515

BRACKET, STEERING RACK HOUSING, NO.2

45516

GROMMET, STEERING RACK HOUSING, NO.1

45517

GROMMET, STEERING RACK HOUSING, NO.2

9011912239

Крепеж

9017014012

Крепеж

9017912067

Крепеж

9538103020

Крепеж

Код

Описание

04445A

GASKET KIT, POWER STEERING GEAR(FOR RACK & PINION)

04455

GASKET KIT, POWER STEERING CONTROL VALVE OVERHOLE

40120

GEAR ASSY,POWER STEERING,REBUILT

44250

GEAR ASSY, POWER STEERING(FOR RACK & PINION)

45046

END SUB-ASSY, TIE ROD, RH

45046A

NUT, CASTLE(FOR TIE ROD END)

45047

END SUB-ASSY, TIE ROD, LH

45514

BRACKET, STEERING RACK HOUSING, NO.1

45515

BRACKET, STEERING RACK HOUSING, NO.2

45516

GROMMET, STEERING RACK HOUSING, NO.1

45517

GROMMET, STEERING RACK HOUSING, NO.2

9011912239

Крепеж

9017014012

Крепеж

9017912067

Крепеж

9538103020

Крепеж

Код

Описание

44201

VALVE SUB-ASSY, POWER STEERING CONTROL

44201A

NUT, LOCK(FOR POWER STEERING CONTROL VALVE)

44201B

SPACER(FOR POWER STEERING CONTROL VALVE)

44201C

RING(FOR POWER STEERING CONTROL VALVE)

44201H

BEARING(FOR POWER STEERING CONTROL VALVE UPPER)

44201P

BEARING(FOR POWER STEERING CONTROL VALVE LOWER)

44204

RACK SUB-ASSY, POWER STEERING

44204A

RING(FOR RACK STEERING PISTON)

44206E

SEAL, OIL, NO.1(FOR POWER STEERING CYLINDER TUBE)

44206F

SEAL, OIL, NO.2(FOR POWER STEERING CYLINDER TUBE)

44206G

SPACER, NO.1(FOR POWER STEERING CYLINDER TUBE)

44206H

SPACER, NO.2(FOR POWER STEERING CYLINDER TUBE)

44240

HOUSING ASSY, POWER STEERING RACK

44253E

SEAT, UNION(FOR POWER STEERING RACK HOUSING)

44253F

SEAL, OIL, NO.1(FOR POWER STEERING RACK HOUSING)

44253G

SEAL, OIL, NO.2(FOR POWER STEERING RACK HOUSING)

44253P

RING, HOLE SNAP(FOR POWER STEERING RACK HOUSING)

44253Q

BUSH(FOR POWER STEERING RACK HOUSING)

44275

STOPPER, CYLINDER END

44275A

RING, HOLE SNAP(FOR CYLINDER END STOPPER)

44277

SEAT, RACK GUIDE

44283

CAP, RACK HOUSING

44418A

TUBE, STEERING RIGHT TURN PRESSURE

44419A

TUBE, STEERING LEFT TURN PRESSURE

45222

COVER, STEERING GEAR DUST

45503

END SUB-ASSY, STEERING RACK

45503B

WASHER, CLAW(FOR STEERING RACK END)

45523

GUIDE, RACK(FOR STEERING GEAR)

45523A

SPRING(FOR STEERING GEAR RACK GUIDE)

45524

CAP, STEERING RACK GUIDE SPRING

45524A

NUT(FOR STEERING RACK GUIDE SPRING CAP)

45535

BOOT, STEERING RACK, NO.1

45535A

CLAMP(FOR STEERING RACK BOOT)

45535B

CLIP(FOR STEERING RACK BOOT)

45536

BOOT, STEERING RACK, NO.2

9014930009

Крепеж

9020822003

Крепеж

Код

Описание

44201

VALVE SUB-ASSY, POWER STEERING CONTROL

44201A

NUT, LOCK(FOR POWER STEERING CONTROL VALVE)

44201C

RING(FOR POWER STEERING CONTROL VALVE)

44201F

SEAL, OIL(FOR POWER STEERING CONTROL VALVE)

44201H

BEARING(FOR POWER STEERING CONTROL VALVE UPPER)

44201J

BEARING(FOR POWER STEERING CONTROL VALVE CENTER)

44201P

BEARING(FOR POWER STEERING CONTROL VALVE LOWER)

44204

RACK SUB-ASSY, POWER STEERING

44204A

RING(FOR RACK STEERING PISTON)

44205

STOPPER SUB-ASSY, CYLINDER END

44205A

RING, O(FOR CYLINDER END STOPPER)

44205B

SEAL, OIL(FOR CYLINDER END STOPPER)

44206E

SEAL, OIL, NO.1(FOR POWER STEERING CYLINDER TUBE)

44206G

SPACER, NO.1(FOR POWER STEERING CYLINDER TUBE)

44210

VALVE ASSY, POWER STEERING CONTROL

44210E

SEAL, OIL(FOR POWER STEERING CONTROL VALVE)

44211

HOUSING, CONTROL VALVE

44218

GASKET, VALVE HOUSING

44240

HOUSING ASSY, POWER STEERING RACK

44275

STOPPER, CYLINDER END

44275C

WIRE(FOR CYLINDER END STOPPER)

44283

CAP, RACK HOUSING

44418A

TUBE, STEERING RIGHT TURN PRESSURE

44418C

RING, O(FOR STEERING TURN PRESSURE TUBE)

44419A

TUBE, STEERING LEFT TURN PRESSURE

45222

COVER, STEERING GEAR DUST

45503

END SUB-ASSY, STEERING RACK

45503B

WASHER, CLAW(FOR STEERING RACK END)

45523

GUIDE, RACK(FOR STEERING GEAR)

45523A

SPRING(FOR STEERING GEAR RACK GUIDE)

45523C

SPACER(FOR RACK GUIDE)

45524

CAP, STEERING RACK GUIDE SPRING

45524A

NUT(FOR STEERING RACK GUIDE SPRING CAP)

45535

BOOT, STEERING RACK, NO.1

45535A

CLAMP(FOR STEERING RACK BOOT)

45535B

CLIP(FOR STEERING RACK BOOT)

45536

BOOT, STEERING RACK, NO.2

9014930009

Крепеж

9020822003

Крепеж

9161160825

Крепеж

Рулевая рейка и наконечники TOYOTA SPRINTER, 1991/06 - 1995/05, 1,3 литра, 16 клапанов, DOHC, EFI, 4 двери, LX SPECIFICATION, EE101, автомат, АКПП, 3 ступени
