Каталог
Ближний ВостокМодель
HILUXДвигатель
2,2 литраКузов
DOUBLE CAB TRUCKКласс
STANDARD TYPEФрейм
YN67Трансмиссия
механика МКПП, 5 скоростейОпции
левый руль GENERAL COUNTRIES STANDARD CARBURETOR SPECIFICATION COMPLETED VEHICLE
Код
Описание
21015
HOUSING SUB-ASSY, COIL
2102
переход к группе запчастей
21077C
BALL, STEEL(FOR AUXILIARY ACCELERATION PUMP)
21112
HORN, AIR
21165
INSULATOR
21171
CHAMBER, DIAPHRAGM
21171A
DIAPHRAGM(FOR DIDPHRAGM CHAMBER)
21191
OPENER
21203
BLEEDER SUB-ASSY, 1ST MAIN AIR
21204
BLEEDER SUB-ASSY, 2ND MAIN AIR
21205
JET SUB-ASSY, SLOW
21208
JET SUB-ASSY, STEP
21209
FLOAT SUB-ASSY
21249
JET, AIR BLEED, NO.2
21251
JET, 1ST MAIN
21253
JET, 2ND MAIN
21255
JET, POWER
21271
SCREW, IDLE ADJUSTING
21273
SCREW, THROTTLE ADJUSTING
21291
GLASS, LEVEL GAGE
21299
NET, PUMP FILTER
21301
VALVE SUB-ASSY, NEEDLE
21312
BALL, STEEL
21335
VALVE, THERMOSTATIC
21353
PLUNGER, PUMP
2151671030
Крепеж
21561
WEIGHT, PUMP DISCHARGE
21576
CLIP, PUMP STRAINER
21611
GASKET, MAIN JET
21612A
GASKET, POWER JET
21614
GASKET, VENTURI
21617
GASKET, MAIN PASSAGE PLUG
21618
GASKET, NEEDLE VALVE SEAT
21622
GASKET, AIR HORN
21625
GASKET, LEVEL GAGE
21631
GASKET, MAIN GUIDE
21641
GASKET(FOR THERMOSTATIC VALVE COVER)
21645
GASKET, DIAPHRAGM, CAP
21659
RING, O(FOR THERMOSTATIC VALVE)
21699
BOOT(FOR PUMP PLUNGER)
21722
SPRING, PUMP DAMPING
21723
SPRING, IDLE ADJUSTING
21724
SPRING, THROTTLE ADJUSTING
21728
SPRING, THROTTLE VALVE RETURN
21736
SPRING, 1ST IDLE CAM
21756
SPRING, BACK(FOR THROTTLE SHAFT)
21763
PIN, FLOAT LEVER
2176536110
Крепеж
2176571030
Крепеж
21781
PLUG, MAIN PASSAGE(FOR CARBURETOR JET)
21784
PLUG, SLOW PASSAGE
21786
PLUG, PUMP PASSAGE
21787
PLUG, PUMP JET
2178736120
Крепеж
21791
RING, SNAP, NO.1(FOR CARBURETOR LINK)
21797
RING, SNAP, NO.4(FOR CARBURETOR LINK)
2179936110
Крепеж
2179971030
Крепеж
2181671030
Крепеж
2181736120
Крепеж
2182444120
Крепеж
2182944150
Крепеж
21833
SCREW, SET, NO.1(FOR CARBURETOR BODY SET)
21842
SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)
2187540020
Крепеж
21934
SOLENOID, THROTTLE VALVE
8803135070
Крепеж
9092504006
Крепеж
Код
Описание
21015
HOUSING SUB-ASSY, COIL
2102
переход к группе запчастей
21112
HORN, AIR
21165
INSULATOR
21171
CHAMBER, DIAPHRAGM
21171A
DIAPHRAGM(FOR DIDPHRAGM CHAMBER)
21191
OPENER
21203
BLEEDER SUB-ASSY, 1ST MAIN AIR
21204
BLEEDER SUB-ASSY, 2ND MAIN AIR
21205
JET SUB-ASSY, SLOW
21208
JET SUB-ASSY, STEP
21209
FLOAT SUB-ASSY
21251
JET, 1ST MAIN
21253
JET, 2ND MAIN
21255
JET, POWER
21258
JET, SLOW
21271
SCREW, IDLE ADJUSTING
21273
SCREW, THROTTLE ADJUSTING
21291
GLASS, LEVEL GAGE
21299
NET, PUMP FILTER
21301
VALVE SUB-ASSY, NEEDLE
2130836110
Крепеж
2130872210
Крепеж
2130873190
Крепеж
21312
BALL, STEEL
21353
PLUNGER, PUMP
21362
SLEEVE, 1ST MAIN WELL
2139873220
Крепеж
2151671030
Крепеж
21576
CLIP, PUMP STRAINER
21611
GASKET, MAIN JET
2161236110
Крепеж
21612A
GASKET, POWER JET
21614
GASKET, VENTURI
21617
GASKET, MAIN PASSAGE PLUG
21618
GASKET, NEEDLE VALVE SEAT
21622
GASKET, AIR HORN
21625
GASKET, LEVEL GAGE
21631
GASKET, MAIN GUIDE
21641
GASKET(FOR THERMOSTATIC VALVE COVER)
21645
GASKET, DIAPHRAGM, CAP
21699
BOOT(FOR PUMP PLUNGER)
21722
SPRING, PUMP DAMPING
2172273190
Крепеж
21723
SPRING, IDLE ADJUSTING
21724
SPRING, THROTTLE ADJUSTING
21728
SPRING, THROTTLE VALVE RETURN
21736
SPRING, 1ST IDLE CAM
2173736110
Крепеж
21756
SPRING, BACK(FOR THROTTLE SHAFT)
21763
PIN, FLOAT LEVER
2176573190
Крепеж
2177636110
Крепеж
21781
PLUG, MAIN PASSAGE(FOR CARBURETOR JET)
21784
PLUG, SLOW PASSAGE
21787
PLUG, PUMP JET
21791
RING, SNAP, NO.1(FOR CARBURETOR LINK)
21797
RING, SNAP, NO.4(FOR CARBURETOR LINK)
2179936110
Крепеж
2179971030
Крепеж
2181671030
Крепеж
2181736120
Крепеж
2182444120
Крепеж
2182944150
Крепеж
21833
SCREW, SET, NO.1(FOR CARBURETOR BODY SET)
21842
SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)
2187540020
Крепеж
21934
SOLENOID, THROTTLE VALVE
9092504006
Крепеж
Код
Описание
21015
HOUSING SUB-ASSY, COIL
2102
переход к группе запчастей
21112
HORN, AIR
21165
INSULATOR
21171
CHAMBER, DIAPHRAGM
21171A
DIAPHRAGM(FOR DIDPHRAGM CHAMBER)
21191
OPENER
21203
BLEEDER SUB-ASSY, 1ST MAIN AIR
21204
BLEEDER SUB-ASSY, 2ND MAIN AIR
21205
JET SUB-ASSY, SLOW
21208
JET SUB-ASSY, STEP
21209
FLOAT SUB-ASSY
21251
JET, 1ST MAIN
21253
JET, 2ND MAIN
21255
JET, POWER
21258
JET, SLOW
21271
SCREW, IDLE ADJUSTING
21273
SCREW, THROTTLE ADJUSTING
21291
GLASS, LEVEL GAGE
21299
NET, PUMP FILTER
21301
VALVE SUB-ASSY, NEEDLE
2130836110
Крепеж
2130872210
Крепеж
2130873190
Крепеж
21312
BALL, STEEL
21335
VALVE, THERMOSTATIC
21353
PLUNGER, PUMP
21362
SLEEVE, 1ST MAIN WELL
2139873190
Крепеж
2151671030
Крепеж
21576
CLIP, PUMP STRAINER
2161236110
Крепеж
21612A
GASKET, POWER JET
21614
GASKET, VENTURI
21617
GASKET, MAIN PASSAGE PLUG
21618
GASKET, NEEDLE VALVE SEAT
21622
GASKET, AIR HORN
21625
GASKET, LEVEL GAGE
21631
GASKET, MAIN GUIDE
21641
GASKET(FOR THERMOSTATIC VALVE COVER)
21645
GASKET, DIAPHRAGM, CAP
21659
RING, O(FOR THERMOSTATIC VALVE)
21699
BOOT(FOR PUMP PLUNGER)
21722
SPRING, PUMP DAMPING
2172273190
Крепеж
21723
SPRING, IDLE ADJUSTING
21724
SPRING, THROTTLE ADJUSTING
21728
SPRING, THROTTLE VALVE RETURN
21736
SPRING, 1ST IDLE CAM
2173736110
Крепеж
21756
SPRING, BACK(FOR THROTTLE SHAFT)
21763
PIN, FLOAT LEVER
2176573190
Крепеж
2177636110
Крепеж
21781
PLUG, MAIN PASSAGE(FOR CARBURETOR JET)
21784
PLUG, SLOW PASSAGE
21787
PLUG, PUMP JET
21791
RING, SNAP, NO.1(FOR CARBURETOR LINK)
21797
RING, SNAP, NO.4(FOR CARBURETOR LINK)
2179936110
Крепеж
2179971030
Крепеж
2181671030
Крепеж
2181736120
Крепеж
2182444120
Крепеж
2182944150
Крепеж
21833
SCREW, SET, NO.1(FOR CARBURETOR BODY SET)
21842
SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)
2187540020
Крепеж
21934
SOLENOID, THROTTLE VALVE
9092504006
Крепеж
