Каталог
ЕвропаМодель
DYNAДвигатель
2,2 литраКузов
TRUCK (EXCLUDING DUMP TRUCK)Фрейм
YU81Трансмиссия
МКПП, 5 скоростейОпции
правый руль HIGH FLAT DECK OPENING ON THREE SIDES BOARDING DECK DOUBLE TIRE GEN IV3
Код
Описание
46101
HANDLE SUB-ASSY, PARKING BRAKE CONTROL
46103
GUIDE SUB-ASSY, PARKING BRAKE PLUNGER
46105
BRACKET SUB-ASSY, PARKING BRAKE PLANGER OR PEDAL
46110C
PIN(FOR PARKING BRAKE HANDLE SET)
46114
PIN, PARKING BRAKE PLUNGER
46117
SLEEVE, PARKING BRAKE PLUNGER
46275
PLATE, PARKING BRAKE RELEASE CAUTION
46301
LEVER SUB-ASSY, PARKING BRAKE INTERMEDIATE
46301B
BUSH(FOR INTERMEDIATE LEVER)
46301D
COLLAR(FOR INTERMEDIATE LEVER)
46301E
PIN, W/HOLE(FOR INTERMEDIATE LEVER)
46301F
SPRING, TORSION(FOR PARKING BRAKE INTERMEDIATE LEVER)
46301G
BOLT(FOR INTERMEDIATE LEVER)
46311
PAWL, PARKING BRAKE
46311A
SPRING(FOR PARKING BRAKE PAWL)
46311B
PIN, PARKING BRAKE PAWL PIVOT
46311D
WASHER, TYPE C(FOR PARKING BRAKE PAWL)
46410
CABLE ASSY, PARKING BRAKE, NO.1
46410D
PIN(FOR PARKING BRAKE FRONT CABLE)
46420
CABLE ASSY, PARKING BRAKE, NO.2
46420E
GROMMET(FOR PARKING BRAKE CABLE CLAMP)
46420F
SEAL, DUST(FOR PARKING BRAKE CABLE)
46420G
SPRING(FOR PARKING CABLE INNER WIRE SET)
46420P
SPACER, PARKING BRAKE
46420Q
RING, E(FOR PARKING BRAKE CABLE)
46430
CABLE ASSY, PARKING BRAKE, NO.3
46481
CONNECTOR, PARKING CABLE
9017908123
Крепеж
9046108225
Крепеж
9046808001
Крепеж
9165140814
Крепеж
9165140820
Крепеж
9412040600
Крепеж
9418041000
Крепеж
9538102520
Крепеж
Код
Описание
46452
BRACKET, PARKING BRAKE CABLE SUPPORT, NO.2
9046110642
Крепеж
9046110645
Крепеж
9046112086
Крепеж
9094901169
Крепеж
9094901170
Крепеж
9161160816
Крепеж
9161160820
Крепеж
9165140825
Крепеж
9411040800
Крепеж
Код
Описание
46501
DRUM SUB-ASSY, PARKING BRAKE
46501A
BOLT, SERRATION(FOR PARKING BRAKE DRUM)
46506
ADJUSTER SUB-ASSY, PARKING BRAKE SHOE, RH OR CENTER
46520
PLATE SUB-ASSY, PARKING BRAKE
4654036010
Крепеж
4655036010
Крепеж
46550A
SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN)
46550C
WASHER, TYPE C(FOR PARKING BRAKE SHOE)
46550E
SPRING, TENSION, NO.2(FOR PARKING BRAKE SHOE RETURN)
46555
SPRING, BRAKE SHOE HOLD DOWN
46556
PIN, SHOE HOLD DOWN SPRING
46577
COVER, ADJUSTING CAM HOLE
4660125011
Крепеж
9011910338
Крепеж
9461311200
Крепеж
Код
Описание
46501
DRUM SUB-ASSY, PARKING BRAKE
46501A
BOLT, SERRATION(FOR PARKING BRAKE DRUM)
46506
ADJUSTER SUB-ASSY, PARKING BRAKE SHOE, RH OR CENTER
46520
PLATE SUB-ASSY, PARKING BRAKE
46540
SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.1
46550
SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.2
46550A
SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN)
46550C
WASHER, TYPE C(FOR PARKING BRAKE SHOE)
46550E
SPRING, TENSION, NO.2(FOR PARKING BRAKE SHOE RETURN)
46550G
SPRING, TENSION, NO.3(FOR PARKING BRAKE SHOE RETURN)
46555
SPRING, BRAKE SHOE HOLD DOWN
46556
PIN, SHOE HOLD DOWN SPRING
46557
CUP, BRAKE SHOE HOLD DOWN
46577
COVER, ADJUSTING CAM HOLE
46601
LEVER SUB-ASSY, PARKING BRAKE SHOE
46612
STRUT, PARKING BRAKE SHOE LEVER
46612B
SPRING, COMPRESSION(FOR PARKING BRAKE SHOE STRUT)
9011910338
Крепеж
9011910339
Крепеж
9461311200
Крепеж
