Передние кресла TOYOTA CORSA/TERCEL, 1983/08 - 1986/05, 1,3 литра, седан, GX SPECIFICATION, AL20, механика, МКПП, 4 ступени

Каталог

Япония

Модель

CORSA/TERCEL

Двигатель

1,3 литра

Кузов

седан

Класс

GX SPECIFICATION

Фрейм

AL20

Трансмиссия

механика МКПП, 4 ступени

Опции

CLEARANCE SONER 3 двери

Код

Описание

71011S

FRAME SUB-ASSY, FRONT SEAT CUSHION, RH

71012S

FRAME SUB-ASSY, FRONT SEAT CUSHION, LH

71071S

COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71072S

COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

71073S

COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71073W

WIRE, FRONT SEAT BACK COVER

71074S

COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71410S

CUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71420S

CUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE)

71430S

BACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71440S

BACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE)

71511S

PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71512S

PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE)

71551S

PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71552S

PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71630S

SPRING ASSY, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71640S

SPRING ASSY, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71753

TRAY, FRONT SEAT UNDER

71812A

RING, HOG, SMALL (FOR FRONT SEAT)

71950

HEADREST ASSY, FRONT SEAT

71956A

SUPPORT, FRONT SEAT HEADREST

72760A

ADJUSTER ASSY, LUMBAR SUPPORT

72791

LEVER, LUMBAR SUPPORT

73515

RAIL, FRONT SEAT UNDER TRAY, NO.1

73516

RAIL, FRONT SEAT UNDER TRAY, NO.2

9038612016

Крепеж

9046804137

Крепеж

9052308001

Крепеж

9331616014

Крепеж

9356014008

Крепеж

Код

Описание

71011S

FRAME SUB-ASSY, FRONT SEAT CUSHION, RH

71012S

FRAME SUB-ASSY, FRONT SEAT CUSHION, LH

71071S

COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71072S

COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

71073S

COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71073W

WIRE, FRONT SEAT BACK COVER

71074S

COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71410S

CUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71420S

CUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE)

71430S

BACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71440S

BACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE)

71511S

PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71512S

PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE)

71551S

PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71552S

PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71630S

SPRING ASSY, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71640S

SPRING ASSY, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71753

TRAY, FRONT SEAT UNDER

71812A

RING, HOG, SMALL (FOR FRONT SEAT)

71950

HEADREST ASSY, FRONT SEAT

71956A

SUPPORT, FRONT SEAT HEADREST

72760A

ADJUSTER ASSY, LUMBAR SUPPORT

72791

LEVER, LUMBAR SUPPORT

73515

RAIL, FRONT SEAT UNDER TRAY, NO.1

73516

RAIL, FRONT SEAT UNDER TRAY, NO.2

9038612016

Крепеж

9052001002

Крепеж

9052308001

Крепеж

9165140616

Крепеж

9356014008

Крепеж

Код

Описание

71811D

SHIELD, FRONT SEAT CUSHION, RH

71812D

SHIELD, FRONT SEAT CUSHION, LH

71861

SHIELD, FRONT SEAT CUSHION, INNER RH

71862

SHIELD, FRONT SEAT CUSHION, INNER LH

72011

ADJUSTER SUB-ASSY, FRONT SEAT, OUTER RH

72011A

SPRING, TENSION (FOR FRONT SEAT ADJUSTER OUTER)

72012

ADJUSTER SUB-ASSY, FRONT SEAT, OUTER LH

72021

ADJUSTER SUB-ASSY, FRONT SEAT, INNER RH

72022

ADJUSTER SUB-ASSY, FRONT SEAT, INNER LH

72130

TRACK ASSY, RH SEAT, INNER

72137

COVER, SEAT TRACK, OUTER RH

72138

COVER, SEAT TRACK, OUTER LH

72140

TRACK ASSY, LH SEAT, INNER

72157

COVER, SEAT TRACK BRACKET, INNER

72210

CABLE ASSY, SEAT TRACK CONTROL

72301

WIRE SUB-ASSY, SEAT TRACK EQUALIZING

72457A

KNOB, SEAT ADJUSTER

72496

KNOB, VERTICAL SEAT ADJUSTER, NO.2

72501C

PIPE SUB-ASSY, RECLINING CONNECTING

72524

HANDLE, RECLINING ADJUSTER RELEASE

72553

COVER, RECLINING PEDAL

9011908335

Крепеж

9011908336

Крепеж

9011910111

Крепеж

9011910117

Крепеж

9014940012

Крепеж

9015480002

Крепеж

9016000800

Крепеж

9016840011

Крепеж

9016840049

Крепеж

9052001002

Крепеж

9324954006

Крепеж

Код

Описание

71811D

SHIELD, FRONT SEAT CUSHION, RH

71812D

SHIELD, FRONT SEAT CUSHION, LH

71861

SHIELD, FRONT SEAT CUSHION, INNER RH

72011

ADJUSTER SUB-ASSY, FRONT SEAT, OUTER RH

72011A

SPRING, TENSION (FOR FRONT SEAT ADJUSTER OUTER)

72012

ADJUSTER SUB-ASSY, FRONT SEAT, OUTER LH

72130

TRACK ASSY, RH SEAT, INNER

72137

COVER, SEAT TRACK, OUTER RH

72138

COVER, SEAT TRACK, OUTER LH

72140

TRACK ASSY, LH SEAT, INNER

72157

COVER, SEAT TRACK BRACKET, INNER

72210

CABLE ASSY, SEAT TRACK CONTROL

72301

WIRE SUB-ASSY, SEAT TRACK EQUALIZING

72457A

KNOB, SEAT ADJUSTER

72496

KNOB, VERTICAL SEAT ADJUSTER, NO.2

72524

HANDLE, RECLINING ADJUSTER RELEASE

72553

COVER, RECLINING PEDAL

9011908080

Крепеж

9011908174

Крепеж

9011908335

Крепеж

9011908336

Крепеж

9011910229

Крепеж

9011910404

Крепеж

9015480002

Крепеж

9016840011

Крепеж

9016840036

Крепеж

9052001002

Крепеж

9324954006

Крепеж

9616000800

Крепеж

Передние кресла TOYOTA CORSA/TERCEL, 1983/08 - 1986/05, 1,3 литра, седан, GX SPECIFICATION, AL20, механика, МКПП, 4 ступени
